In this video we will discuss nesting angular components i.e including a component inside another component.
Angular 2 is all about components. A component in Angular allows us to create a reusable UI widget. A component can be used by any other component. Let’s look at a simple example of nesting a component inside another component.
Create a page that displays Employee details. This page should be composed of 2 angular components
AppComponent – This component is the root component and displays just the page header.
EmployeeComponent – This component is the child component and displays the Employee details table. This child component will be nested inside the root AppComponent.
Step 1 : Right click on the “App” folder and add a new folder. Name it “employee”. We will create our EmployeeComponent in this folder.
Step 2 : Right click on the “employee” folder and add a new HTML page. Name it employee.component.html. Copy and paste the following HTML.
[table]
[tr]
[td]First Name[/td]
[td]{{firstName}}[/td]
[/tr]
[tr]
[td]Last Name[/td]
[td]{{lastName}}[/td]
[/tr]
[tr]
[td]Gender[/td]
[td]{{gender}}[/td]
[/tr]
[tr]
[td]Age[/td]
[td]{{age}}[/td]
[/tr]
[/table]
Step 3 : Right click on the “employee” folder and add a new TypeScript file. Name it employee.component.ts. Copy and paste the following code in it. At this point we have our child component EmployeeComponent created. Next let’s create the root component – AppComponent.
import { Component } from ‘@angular/core’;
@Component({
selector: ‘my-employee’,
templateUrl: ‘app/employee/employee.component.html’
})
export class EmployeeComponent {
firstName: string = ‘Tom’;
lastName: string = ‘Hopkins’;
gender: string = ‘Male’;
age: number = 20;
}
Step 4 : We are going to use the root component to just display the page header. So in “app.component.ts” file, include the following code. Notice, since the View Template HTML is just 3 lines we have used an inline template instead of an external template. Angular2 recommends to extract templates into a separate file, if the view template is longer than 3 lines.
import { Component } from ‘@angular/core’;
@Component({
selector: ‘my-app’,
template: `[div]
[h1]{{pageHeader}}[/h1]
[/div]`
})
export class AppComponent {
pageHeader: string = ‘Employee Details’;
}
At this point if we run the application, we only see the page header – “Employee Details”, but not the table which has the employee details. To be able to display employee details table along with the page header, we will have to nest EmployeeComponent inside AppComponent. There are 2 simple steps to achieve this.
Please refer to the text article using the link below for the code used in the demo
